MORSE installation

MORSE in two minutes (if you run Debian or Ubuntu!)

Open a console, type sudo apt-get install morse-simulator (or click here: install morse-simulator), then:

$ morse create my_first_sim
$ morse run my_first_sim

This will start running a simple simulation straight away!


Installing the morse simulation will also ensure that you have full support for ros, yarp, moos, and in fact, all of the middlewares supported by MORSE (with a few corner cases for the pocolibs middleware that may require manual compilation. Read on).


Automatic installation of middlewares’ support requires MORSE >=1.3! Ubuntu =< 15.04 and Debian Wheezy/Jessie only ship MORSE 1.2.2: in that case, you still need to install MORSE manually if you want to use MORSE with ROS/YARP/MOOS/pocolibs. Read on.

If you’ve successfully installed the simulator, you can now dive into the Quickstart tutorial!

System requirements

Supported operating systems

Only Linux (x86, x86_64) is currently officially supported. MORSE is mainly developed on Fedora and Ubuntu, but it should work fine on other Linux distributions.

It should also work on UNIX systems more generally, such as FreeBSD and Apple MacOSX. Some successful testing has been done on OSX 10.8 (see below for the Homebrew recipe).

Windows is supported, but not fully tested.


A decent machine is required (for example, an Intel i5 with 4GB RAM should be sufficient).

To display textures correctly in the simulator, as well as to generate images using the simulated cameras, you will need to have a graphics card that supports GLSL shading. The Blender website lists the following GLSL-compatible graphics cards:

  • ATI Radeon 9x00, Xx00, X1x00, HD2x00 and HD3x00 series and newer.
  • NVidia Geforce FX, 6x00, 7x00, 8x00, 9x00 and GTX 2x0 and newer.

If you don’t need cameras and OpenGL textures/shaders, you are advised to run your simulation in fastmode (refer to the simulation’s Builder API) for vastly improved load time and runtime performance.

Packaged versions (Debian, Ubuntu, Windows)

MORSE is available on Debian >= Wheezy and Ubuntu >= 13.04. You can install the package morse-simulator with your preferred software package manager:

$ sudo apt-get install morse-simulator

You can also install the Python bindings with:

$ sudo apt-get install python3-morse-simulator


Automatic installation of middlewares’ support requires MORSE >=1.3! Ubuntu =< 15.04 and Debian Wheezy/Jessie only ship MORSE 1.2.2: in that case, you need to install MORSE manually if you want to use MORSE with ROS/YARP/MOOS/pocolibs. Continue to the next section.

Windows users can find a convenient Morse installer on the Morse Github page. Note that Blender (must be V2.78) is required to be installed first. Blender and Morse must both 32-bit installs or both be 64-bit installs to ensure compatibility between the two packages.

Blender V2.78 can be downloaded from the Blender website.

You can also easily install MORSE with:

See their associated documentation for details.

Manual installation


The directory where MORSE is installed will be referred to as $MORSE_ROOT in this document.


  • cmake
  • Python (>= 3.3)
  • python-dev package
  • Blender (>= 2.65) built with Python >= 3.3. You can simply get a binary from Blender website
  • numpy for Python 3 (often py3-numpy `` or ``python3-numpy)


If you plan to build packages for MORSE, please read the notes on packaging below.


If you use a Blender binary, numpy is included within it.


If building on Windows, ensure that your Python version and architecture matches the bundled Python in Blender (currently Python 3.5.3 for Blender 2.79).



Clone with git or download the latest version of the source code:

$ git clone

The latest revision is always reasonably stable, and we recommend that you use it. However, if you prefer to use the stable branch, you can checkout the 1.4_STABLE branch or download it from here.

MORSE relies on a standard CMake workflow: go to the directory where you downloaded the MORSE source and type:

$ mkdir build && cd build
$ cmake ..
$ sudo make install

While the default set of options should cover most users needs, you can use ccmake .. to inspect (and modify) all the available options.

The optional $MORSE_BLENDER environment variable can be set to tell the simulator where to look for Blender if it is not accessible from the path.

You can check your configuration is okay with:

$ morse check


When updating MORSE to a more recent version, you only have to do:

$ git pull --rebase master
$ cd build
$ sudo make install

Once MORSE is successfully installed and checked you are read for the Quickstart tutorial!


Download the latest version of the source code. It is stored in a git repository:

$ git clone

The MORSE_BLENDER environment variable should be set the the location and filename of the Blender executable (ie “C:Program FilesBlenderblender.exe”).

Additionally, both cmake and Python should be on the system path.

Go to the directory where you have previously downloaded the MORSE source. Then run the winbuild.bat script.

By default, MORSE will install in C:morse. You can easily change the install directory by editing the MORSE_ROOT variable in winbuild.bat

Middleware-specific notes

  • ros Since MORSE runs with Python 3, you need to install the packages python3-catkin-tools and python3-yaml. If these packages are not available for your distribution, check the manual instructions.
  • yarp If needed, instructions on how to install YARP on your system are available here.
  • moos If needed, instructions on how to install MOOS on your system are available here.
  • pocolibs pocolibs support requires specific steps (some bindings require a compilation). The instructions are available here.


While not officially supported, MORSE is also known to work with OpenRTM.

Advanced components

If you want to distribute your simulation in a multinode infrastructure, MORSE provides by default a socket service for multinode synchronization. If you want to use HLA, you must first install the CERTI and PyHLA packages:

Notes for packaging

By default, MORSE automatically installs support for every supported middleware as well as the Python bindings pymorse.

However, when you package MORSE yourself, you may want to separate the support for the various middlewares from the core of the simulator. This can be easily achieved by passing options to CMake like -DBUILD_ROS_SUPPORT=OFF or PYMORSE_SUPPORT=OFF.

-DBUILD_CORE_SUPPORT=OFF disables the installation of the simulator’s core. Doing this allows you to separately package the support for the various middlewares/bindings.

Installation troubleshooting

In case of problems installing or running MORSE, check the list of Frequently Asked Questions.
